Connections

• 5 servo inputs – an IBUS/SBUS/SUMD signal can also be connected to Gas/Data (automatic detection)
• 5 servo outputs (adjustable, factory settings see above)
• Off/On/Standby switch
• Standby jumper for configuring sound and control mode
• 6 EasyBus outputs
• I2C expansion port
• Micro-USB port
• SD card slot (max. 32 GB, FAT32 formatted)
• Speaker connection (4 Ohm or higher)
• 10A switching outputs
• Status LED
• 4 expansion pins for plug-in modules
